ALTIQ™ Jimny (2018+) 32" LED Light Bar Kit – Vehicle-Specific Stealth Mounting System

Upgrade Your Night Driving Without Changing Your Jimny

Designed exclusively for the 2018+ Suzuki Jimny JB74, the ALTIQ™ 32" LED Light Bar Kit delivers a significant lighting upgrade while preserving the factory appearance of your vehicle. Unlike conventional light bar installations, this complete kit mounts directly to the factory mounting points, eliminating the need for a bull bar, rally bar, drilling, cutting, or permanent modifications.

Available with either a sleek Single Row or high-output Double Row light bar, the system is engineered to integrate cleanly behind the grille while providing exceptional forward illumination for touring, off-road adventures, rural driving, and low-light conditions.

Why Choose the ALTIQ™ Jimny Light Bar Kit?

If you're looking for a lighting solution that combines straightforward installation, vehicle-specific engineering, and outstanding performance, this kit offers everything required in one package. Every mounting bracket has been purpose-built for the Suzuki Jimny JB74, ensuring an accurate fit without relying on universal hardware or fabrication.

The included plug-and-play wiring harness and high beam adapter simplify installation while maintaining a clean, professional finish.

Key Features

Designed specifically for Suzuki Jimny JB74 (2018+)
No bull bar, rally bar, drilling, cutting, or permanent modifications required
Mounts directly using factory mounting points
Installation can be completed in under 15 minutes using basic tools
Available with either a 32" Single Row or Double Row Hybrid LED Light Bar
Bespoke Jimny-specific mounting brackets
Plug-and-play wiring harness included
Vehicle-specific high beam piggyback adapter included
Hybrid Tri-Optic beam pattern combining Spot, Combo and Flood lighting
Engineered with GE Lexan 3mm lens
DuPont Midnight Paint finish
316L marine-grade stainless steel fasteners
Waterproof rating: IP68–IP69K
Backed by a 10-Year Warranty

Performance

Compared with the factory high beams, the ALTIQ™ 32" Hybrid Double Row Light Bar delivers substantial improvements in usable light output.

Measured Performance

Factory high beam: 1,014 Lux at 6 metres
ALTIQ™ Hybrid Double Row: 11,900 Lux at 6 metres

1 Lux Distance

Factory high beam: 207 metres
ALTIQ™ 32" Hybrid Double Row LED Light Bar: 878 metres

What's Included

1 × ALTIQ™ Hybrid Light Bar (Single Row or Double Row)
2 × Rear under-mount light bar brackets
2 × Jimny-specific mounting brackets
1 × Fast Fit plug-and-play wiring harness
1 × High beam adapter for Suzuki Jimny 2018+
Stainless steel mounting hardware
Stainless steel Allen key set

Technical Specifications

Specification	Single Row	Double Row
LUX Distance	1 Lux @ 626m	1 Lux @ 878m
Lumens	7,380	14,850
LEDs	32 × Genuine 5W OSRAM P9 Chips	60 × Genuine 5W OSRAM P9 Chips
Lens	GE Lexan 3mm	GE Lexan 3mm
Finish	DuPont Midnight Paint	DuPont Midnight Paint
Fasteners	316L Marine Stainless Steel	316L Marine Stainless Steel
Waterproof Rating	IP68–IP69K	IP68–IP69K
Input Voltage	10–30V DC	10–30V DC
Current Draw	9.833A @ 12V	11.33A @ 12V
Colour Temperature	5700K @ 82+ CRI	5700K @ 82+ CRI
Wiring Harness	14 Gauge Dual DT Output, Negative and Positive Switched Headlight Compatible	14 Gauge Dual DT Output, Negative and Positive Switched Headlight Compatible
Weight	2.25kg (including brackets)	3.20kg (including brackets)
Warranty	10 Years	10 Years

Purpose-Built for the JB74 Platform

Every bracket in this kit has been engineered specifically for the Suzuki Jimny JB74 platform. Developed using dedicated vehicle measurements and precision design processes, the mounting system delivers a secure fit while maintaining a tidy, factory-style appearance behind the grille.

Whether you prefer the discreet profile of the Single Row light bar or the more commanding look of the Double Row version, both options are designed to integrate seamlessly with the vehicle while providing dependable lighting performance.

Vehicle Compatibility

Suzuki Jimny JB74 (2018+)
