Outback Armour Adjustable Bypass Lift Kit for Ford Ranger PX3 (August 2018 - 2022)
- β Engineered for harsh conditions
- β Assembled option
- β 3-4 Year / Unlimited km warranty*
βContact us on chat for personalised quote including delivery
π€ Not sure what lift kit you need for your rig? Get a personalised quote HERE.
Lift Kits
Checkout securely with
- Description
- Get A Quote
- π‘οΈ Fitment Advice
Designed and engineered in Australia by Outback Armour, this system features an adjustable internal bypass that offers more than 20 stages of velocity-sensitive damping control. This allows both front and rear settings to be adjusted as needed to suit accessories, load weight, terrain, driving conditions, and personal comfort preferences.
Increasing the bypass (-) provides a softer, more comfortable ride, while decreasing the bypass (+) delivers greater control.
A high-strength polymer adjustable spring seat is included to fine-tune ride height or compensate for additional accessories. Each unit is supplied with a complete fitting kit, including rubber bushes.
The maximum recommended ride height, measured from the centre of the wheel to the guard, is 575mm for the Prado and 560mm for the FJ Cruiser.
Specifications:
- Bushings: Natural rubber
- Maximum CWG: 575mm
- Finish: Orange baked enamel
- Piston: 45mm high-flow performance
- Piston rod: 20mm hard chromed
- Protection: Synthetic dust boot
- Seal: Triple-lip high-temperature Viton
- Shock construction: 65mm twin tube
- Shock range: Adjustable Internal Bypass (ADJ)
- Steel tube: Hydraulic pressure tube
*Images are for illustrative purposes only. Actual products may vary in appearance and should be used as a guide only.
Β
Ford Ranger PX3 Front Lift Kits Include:
Front - Adjustable Bypass Trail - 50mm (approx unladen)
- Threaded - height adjustable spring seat
- 20+ settings for damping control
- Suits oem bumper
Adjustable Bypass - Front Strut Β Β OASU0865018-ADJ x2 ea.
Front - Trail Β Β OASU1048001 x1 pr.
Strut Mount Β Β OASU0750001 x2 ea.
Strut mount locator Β Β OAPSS080 x2 ea.
Front -Β Adjustable Bypass Expedition - 50mm (approx 50-100kgs)
- Threaded - height adjustable spring seat
- 20+ settings for damping control
- Suits steel bullbar
Adjustable Bypass - Front Strut Β Β OASU0865018-ADJ x2 ea.
Front - Expedition/Expedition HD Β Β OASU1048003 x1 pr.
Strut Mount Β Β OASU0750001 x2 ea.
Strut mount locator Β Β OAPSS080 x2 ea.
Front - Adjustable BypassΒ Expedition HD - 50mm (approx 100-150kgs)
- Threaded - height adjustable spring seat
- 20+ settings for damping control
- Suits steel bullbar & winch
Adjustable Bypass - Front Strut Β Β OASU0865018-ADJ x2 ea.
Front - Expedition/Expedition HD Β Β OASU1048003 x1 pr.
Strut Mount Β Β OASU0750001 x2 ea.
Strut mount locator Β Β OAPSS080 x2 ea.
Ford Ranger PX3 Rear Lift Kits Include:
Rear -Β Adjustable Bypass Trail - 40mm (approx unladen)
- 20+ settings for damping control
Adjustable Bypass - Rear Shock Β Β OASU0165009L-ADJ x2 ea.
Trail Β Β OASU1148005 x2 ea.
UBolt - M14 x 88 ID (RND) x 210 L Β Β OASU2388001 x4 ea.
Greasable Pin Β Β OASU2500042 x2 ea.
Greasable Shackle - Reverse Β Β OASU2400060REV x2 ea.
Leaf Spring Bush Kit Β Β OASU210028K x1 ea.
Centre Bearing Spacer Kit Β Β OASU3748001 x1 ea.
Rear - Adjustable Bypass Expedition - 40mm (approx 150kg load)
- 20+ settings for damping control
Adjustable Bypass - Rear Shock Β Β OASU0165009L-ADJ x2 ea.
Expedition Β Β OASU1148001 x2 ea.
UBolt - M14 x 88 ID (RND) x 210 L Β Β OASU2388001 x4 ea.
Greasable Pin Β Β OASU2500042 x2 ea.
Greasable Shackle - Reverse Β Β OASU2400060REV x2 ea.
Leaf Spring Bush Kit Β Β OASU210028K x1 ea.
Centre Bearing Spacer Kit Β Β OASU3748001 x1 ea.
Rear - Adjustable Bypass Expedition HD - 40mm (approx 300kg load)
- 20+ settings for damping control
Adjustable Bypass - Rear Shock Β Β OASU0165009L-ADJ x2 ea.
Expedition HD Β Β OASU1148002 x2 ea.
UBolt - M14 x 88 ID (RND) x 210 L Β Β OASU2388001 x4 ea.
Greasable Pin Β Β OASU2500042 x2 ea.
Greasable Shackle - Reverse Β Β OASU2400060REV x2 ea.
Leaf Spring Bush Kit Β Β OASU210028K x1 ea.
Centre Bearing Spacer Kit Β Β OASU3748001 x1 ea.
Rear - Adjustable Bypass Expedition XHD - 40mm (approx 500kg load)
- 20+ settings for damping control
Adjustable Bypass - Rear Shock Β Β OASU0165009L-ADJ x2 ea.
Expedition XHD Β Β OASU1148003 x2 ea.
UBolt - M14 x 88 ID (RND) x 210 L Β Β OASU2388001 x4 ea.
Greasable Pin Β Β OASU2500042 x2 ea.
Greasable Shackle - Reverse Β Β OASU2400060REV x2 ea.
Leaf Spring Bush Kit Β Β OASU210028K x1 ea.
Centre Bearing Spacer Kit Β Β OASU3748001 x1 ea.
