KMC Impact FFT Wheels KM733 Matte Black
Checkout securley with
- Description
- Vehicle Guide
- Wheel Offset Chart
- Delivery
- 🛡️ Fitment Advice
Conquer every trail and highway with confidence — the KMC IMPACT FFT wheel fuses rugged performance, advanced engineering, and aggressive styling into one premium package. Designed for off-road enthusiasts, overland builds, Jeeps, and heavy-duty trucks, this wheel brings both form and function to your ride.
Built for real-world conditions, it features KMC’s Bead Retention System (BRS). Precision-machined grooves grip the tire bead securely, enhancing traction at low tire pressures and reducing the need for remounting — ideal for those who push limits off-road while maintaining DOT compliance for everyday driving.
Available in multiple finishes including Gloss Black, Gloss Silver with Machined Face, Matte Black, and Matte Bronze, the IMPACT FFT forged suits a wide range of vehicle aesthetics.
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size |
| KM733MX17855000 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 5X127 | 4.75 | 0mm | 71.5 | 26.01 lbs | 2650 | 1.8 |
| KM733MX17856425 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X114.3 | 5.73 | 25mm | 66.06 | 25.57 lbs | 2650 | 1.58 |
| KM733MX17857725 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X120 | 5.73 | 25mm | 66.9 | 25.57 lbs | 2650 | 1.58 |
| KM733MX17853825 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X130 | 5.73 | 25mm | 84.1 | 26.01 lbs | 2650 | 1.58 |
| KM733MX17856300 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X135 | 4.75 | 0mm | 87.1 | 26.46 lbs | 2650 | 1.8 |
| KM733MX17856325 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X135 | 5.73 | 25mm | 87.1 | 26.23 lbs | 2650 | 1.58 |
| KM733MX17856800 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X139.7 | 4.75 | 0mm | 106.1 | 25.79 lbs | 2650 | 1.8 |
| KM733MX17856825 | KM733 IMPACT FFT | MATTE BLACK | 17X8.5 | 6X139.7 | 5.73 | 25mm | 106.1 | 25.57 lbs | 2650 | 1.58 |
| KM733MX18905000 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 5X127 | 5 | 0mm | 71.5 | 28.44 lbs | 2650 | 1.8 |
| KM733MX18906300 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 6X135 | 5 | 0mm | 87.1 | 28.88 lbs | 2650 | 1.8 |
| KM733MX18906318 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 6X135 | 5.71 | 18mm | 87.1 | 28.44 lbs | 2650 | 1.69 |
| KM733MX18906818 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 6X139.7 | 5.71 | 18mm | 106.1 | 27.56 lbs | 2650 | 1.69 |
| KM733MX18906800 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 6X139.7 | 5 | 0mm | 106.1 | 28.00 lbs | 2650 | 1.8 |
| KM733MX18908000 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X165.1 | 5 | 0mm | 125.1 | 32.63 lbs | 4500 | 1.8 |
| KM733MX18908018 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X165.1 | 5.71 | 18mm | 125.1 | 32.63 lbs | 4500 | 1.81 |
| KM733MX18908700 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X170 | 5 | 0mm | 125.1 | 32.63 lbs | 4500 | 1.8 |
| KM733MX18908718 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X170 | 5.71 | 18mm | 125.1 | 32.63 lbs | 4500 | 1.81 |
| KM733MX18908800 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X180 | 5 | 0mm | 124.2 | 32.63 lbs | 4500 | 1.8 |
| KM733MX18908818 | KM733 IMPACT FFT | MATTE BLACK | 18X9 | 8X180 | 5.71 | 18mm | 124.2 | 32.63 lbs | 4500 | 1.81 |
Checkout our full range of KMC Wheels.
This is to be taken as a guide only. We have listed below a few popular vehicle makes with wheel sizes & offsets.
THESE WHEELS MAY FIT OTHER VEHICLES. YOUR VEHICLE MAY ALSO BE ABLE TO FIT OTHER SIZES.
Talk with our online chat if you have quesitons about sizing.
Enter your registration number and state when you place your order and our team will ensure the correct wheel is shipped to fit your vehicle.
| VEHICLE | POPULAR SIZES | POPULAR OFFSET |
| Ford Ranger PX-PXIII No Flares (2011 - 2022) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +30 to 35mm |
| Ford Ranger PX-PXIII With Flares (2011 - 2022) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +20 to 30mm |
| Ford Ranger Next Gen No Flares (2022+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +30 to 55mm |
| Ford Ranger Next Gen With Flares (2022+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +20 to 30mm |
| Isuzu D-Max (2012 - 2020) |
18x8, 18x8.5, 18x9, 20x9 | +10 to 25mm |
| Isuzu D-Max (2021+) |
18x8, 18x8.5, 18x9, 20x9 | +10 to 25mm |
| Mazda BT50 (2011 - 2020) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +30 to 35mm |
| Mazda BT50 (2020+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 19x8.5 | +30 to 33mm |
| Mitsubishi Triton MQ (2015 - 2018) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +15 to 35mm |
| Mitsubishi Triton MR (2018+) |
18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +18 to 35mm |
| Nissan Navara D22 Series 1 (2000 - 2015) |
16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5 | +30 to 40mm |
| Nissan Navara D23 Series 3 - Cab Chassis (2015+) |
16x7 | +30 to 45mm |
| Nissan Navara D23 Series 3 - Dual Cab (2015+) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +30 to 35mm |
| Toyota Hilux N70 KUN Facelift No Flares (2011 - 2015) |
15x6.5, 16x7 | +30 to 40mm |
| Toyota Hilux N80 GUN Revo (2015 - 2022) |
18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +15 to 30mm |
| Toyota LandCruiser 200 Series | 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +35mm |
| Toyota LandCruiser 300 Series | 17x18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +35 to 40mm |
| Volkswagen Amarok (2011+) |
16x8,17x8, 17x8.5, 18x8, 18x8.5 | +30 to 40mm |
Wheel Offset is the clearance between the inside of the wheel and the strut housing. It will also show how far the outside of the wheel edge will extend or retract. If you reduce the inner clearance too much or push the wheel out too far, the tire might rub or not fit at all. This calculator is for information purposes only and we do not guarantee fitment based on this calculator alone.
You can also try using this free online WHEEL CALCULATOR.
Our team are also available on online chat during business hours to assist in choosing the correct size wheel for your vehicle.
Checkout our range online or chat with our team via online chat if you need help choosing the right size.
Our range includes Ford Ranger wheel rims, Toyota Hilux wheel rims, VW Amarok wheel rims, Mazda BT50 wheel rims, Isuzu Dmax & MUX wheel rims, and many more.
