The PJ and PK Ranger shares much of its running gear with the BT-50 of the same era, and after years of work most are sitting on tired torsion bars and flattened rear leaves. That leaves the ute nose-down, saggy at the back and short on clearance. This EFS kit lifts the 2006 to 2011 Ranger 4x4 by around 35mm and restores a firm, level stance.
Heavy-duty torsion bars and a front shock mount reinforcement kit look after the front end, while new raised leaf packs, bushes, U-bolts and greasable shackles rebuild the rear. EFS Elite shocks are fitted at all four corners.
Choose Your Shock
Elite
The Elite series is the shock supplied for the PJ/PK Ranger. It is a dependable twin-tube shock that copes well with work loads, daily driving and gravel roads.
- 35mm bore twin-tube design
- Hardened 15mm chrome piston rod
- Valving matched to the heavy-duty torsion bars and raised leaf springs
Rear Load Options
- 0-150kgs: an empty tray or light everyday gear. Rated for up to about 200kg.
- 300kgs: a constant load such as a canopy, toolboxes or touring gear. Rated for a constant 200-400kg.
What's Included
- 2 x EFS Elite front shock absorbers
- Front shock mount reinforcement kit
- Heavy-duty front torsion bars
- 2 x EFS Elite rear shock absorbers
- 2 x raised rear leaf spring packs, rated to your selected rear load
- Rear spring bushes
- Rear U-bolts
- Rear greasable shackles
Fitment
- Ford Ranger PJ and PK 4x4, 2006 to 2011
- Not suitable for 2WD models or the 2011+ PX Ranger
