Brown Davis 175L Long Range Fuel Tank For Toyota LandCruiser 100/105 Series 1998–2007
- ✅ 175 litre replacement capacity — increases total fuel capacity to 265L, replacing the factory 55L sub-tank
- ✅ Direct bolt-in solution — retains standard filler point, fuel gauge, and pump assembly
- ✅ High-grade aluminised steel construction — strength of steel with corrosion resistance of aluminium
- ✅ Internal baffles and swirl pot — prevents fuel slosh and allows use of every last litre
- ✅ Flush-mounted magnetic drain plug — easy contaminated fuel removal, protected from off-road damage
- ✅ Suits TL100R1 (105 Series Live Axle) & TL100R3 (100 Series IFS / Lexus LX470)
- ✅ 3-year manufacturer's warranty — backed by Brown Davis, Australia's most trusted tank brand since 1978
- ✅ All hardware and parts supplied — complete installation kit included
Checkout securley with
- Description
- Specifications
- Comparison
- Compatibility
- Installation Instructions
- 🛡️ Fitment Advice
Brown Davis 175 Litre Replacement Long Range Fuel Tank for Toyota LandCruiser 105 Series (Live Axle) (1998–2007)
The Brown Davis 175 Litre Replacement Long Range Fuel Tank is the ultimate fuel capacity upgrade for Toyota LandCruiser 105 Series owners who refuse to let a fuel stop cut their adventure short. Engineered and manufactured in Australia since 1978, Brown Davis has built a reputation as the country's most trusted name in long range fuel solutions — and this tank is a testament to that legacy.
This replacement tank directly substitutes the factory 55 litre sub-tank, bringing your total fuel capacity to an impressive 265 litres — a massive increase that dramatically extends your driving range across Australia's most remote and challenging terrain. Whether you're crossing the Simpson Desert, navigating the Gibb River Road, or towing a caravan across the Nullarbor, this tank is engineered to keep you going further with fewer stops.
At Brixton 4x4, we stock the full Brown Davis range because we believe in fitting our customers with products that are genuinely built for Australian conditions. The TL100R1 / TL100R3 is a direct bolt-in solution that retains the vehicle's standard filler point, fuel gauge, and pump assembly — minimising modifications and simplifying the installation process.
Fits: Toyota LandCruiser 105 Series (Live Axle) 1998–2007 | Toyota LandCruiser 100 Series (IFS) 1998–2007 | Lexus LX470 1998–2007
Note: Removal of the spare wheel is required for installation. Professional installation is recommended.
Why Choose the Brown Davis Long Range Fuel Tank?
Brown Davis has been manufacturing long range fuel tanks in Australia since 1978. Every tank is laser cut from high-grade aluminised steel, folded for superior strength, expertly welded using precision jigs, and pressure tested before leaving the factory. The result is a fuel tank built to withstand the harshest outback conditions your LandCruiser will ever face.
Available at Brixton 4x4, this tank is backed by a 3-year manufacturer's warranty and comes complete with all parts and hardware required for installation.
Key Features
- 175 litre replacement capacity — replaces the factory 55L sub-tank for a total combined capacity of 265 litres
- High-grade aluminised steel construction — strength of steel with the corrosion resistance of aluminium, no rust
- Tapered approach angle — reduces frontal impact risk and improves ramp-over clearance
- Internal longitudinal and lateral baffles — minimises fuel slosh and reinforces tank structure
- Internal swirl pot — traps fuel around the pick-up point so you can run the tank to the last few litres
- Gusseted brackets with double thickness pads — spreads mounting loads for a secure and reliable fit
- Retains standard filler point — no modifications to the vehicle's original filling system required
- Reuses factory fuel pump sender flange — standard fuel gauge and pump assembly retained
- Roll-over check valve and expansion box — safe fuel expansion and venting in all orientations
- Fast-fill breather — rapid filling and reduced bowser shut-off
- Flush-mounted magnetic drain plug — easy draining of contaminated fuel, protected from damage
- Cushion clamps — securely retains fuel lines to prevent kinking and damage
- 3-year manufacturer's warranty — backed by Brown Davis' Australia-wide support network
- All hardware and parts supplied — everything needed for installation included in the box
| Part Number (105 Series Live Axle) | TL100R1 |
| Part Number (100 Series IFS / Lexus LX470) | TL100R3 |
| Tank Type | Replacement |
| Capacity | 175 Litres |
| Tank Location | Replaces factory 55L sub-tank |
| Filler Point | Retains standard filler point |
| Fuel Supply Method | Standard |
| Material | High-grade aluminised steel |
| Fitting Time (approx.) | 3 hours |
| Modifications Required | Removal of spare wheel |
| Warranty | 3 Years (Brown Davis) |
| Brand | Brown Davis |
| Standard Setup | With Brown Davis 175L Tank | |
|---|---|---|
| Main Tank Capacity | 90L | 90L |
| Sub-Tank Capacity | 55L (factory) | 175L (Brown Davis) |
| Total Capacity | 145L | 265L |
| Approx. Range (12L/100km) | ~1,208 km | ~2,208 km |
| Additional Range Gained | — | ~1,000 km |
Range figures are approximate and will vary based on driving conditions, load, terrain, and fuel consumption.
TL100R1 — Suits Toyota LandCruiser 105 Series (Solid Front Axle / Live Axle)
| Year | Model / Variant | Engine |
|---|---|---|
| 1998 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 1999 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2000 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2001 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2002 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2003 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2004 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2005 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2006 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
| 2007 | 105 Series – Standard, RV, GXL | Petrol & Diesel |
TL100R3 — Suits Toyota LandCruiser 100 Series (IFS) & Lexus LX470
| Year | Model / Variant | Engine |
|---|---|---|
| 1998 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 1999 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 2000 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 2001 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 2002 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 2003 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
| 2004 | 100 Series – GXL, Kakadu, Sahara, VX & Lexus LX470 | V8 Petrol & Turbo Diesel |
- 1. Remove the vehicle's spare wheel to gain access to the sub-tank mounting location.
- 2. Drain and safely remove the factory 55 litre sub-tank, disconnecting all fuel lines, sender wiring, and mounting hardware.
- 3. Offer up the Brown Davis 175L tank to the mounting location and align all bracket points with the vehicle's existing fixings.
- 4. Reconnect the standard fuel pump sender flange — the Brown Davis tank is designed to reuse the vehicle's original equipment.
- 5. Reconnect all fuel lines using the supplied cushion clamps to secure lines and prevent kinking.
- 6. Attach the filler tube to the vehicle's original filling point — no modifications to the filler neck are required.
- 7. Torque all mounting bolts to specification, check all connections are secure, and inspect for any leaks before refuelling.
For further assistance, please contact our support team.
