The Black Rhino Arsenal BRARS is a military-inspired off-road wheel built for the overland explorer who wants their rig to look as capable as it performs. The design draws its visual language from modern defence vehicles — a bolted wheel face, chiselled window accents, and an overall tactical aesthetic that sets it apart from anything in the standard aftermarket catalogue. This isn't a wheel that tries to look tough; it's one that was designed from the ground up to be it.
The Arsenal covers an exceptionally wide fitment range, available in 16", 17", 18", and 20" diameters across 5-lug, 6-lug, and 8-lug bolt patterns with offsets spanning -44mm to +38mm. Whether you're running a stock-height daily, a lifted truck, or a serious off-highway build, there's an Arsenal fitment to suit. The Sand on Black finish pairs a warm sand-toned face against a black base — a two-tone combination that complements the wheel's mil-spec character and looks at home on any adventure-built 4WD.
For added off-road recovery capability, consider pairing your wheels with Maxtrax recovery tracks.
Specifications
| Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load Rating |
|---|---|---|---|---|---|---|
| 16X8 | 5X160 | 6 | 38mm | 65.07 | 25.13 lbs | 3300 |
| 16X8 | 6X130 | 6 | 38mm | 84.1 | 24.03 lbs | 3300 |
| 16X8 | 6X139.7 | 4.11 | -10mm | 112.1 | 25.57 lbs | 2700 |
| 17X8 | 5X114.3/5X127 | 5.68 | 30mm | 72.56 | 32.56 lbs | 2700 |
| 17X8 | 6X130 | 6 | 38mm | 84.1 | 28.44 lbs | 3300 |
| 17X9.5 | 5X127/5X139.7 | 4.54 | -18mm | 78.1 | 37.18 lbs | 2500 |
| 17X9.5 | 5X139.7/5X150 | 5.25 | 0mm | 110.1 | 34.98 lbs | 2500 |
| 17X9.5 | 6X135/6X139.7 | 4.54 | -18mm | 106.1 | 37.18 lbs | 2500 |
| 17X9.5 | 6X135/6X139.7 | 5.72 | 12mm | 106.1 | 32.56 lbs | 2500 |
| 17X9.5 | 8X165.1 | 4.54 | -18mm | 122.4 | 36.38 lbs | 3640 |
| 18X8 | 5X114.3/5X127 | 5.68 | 30mm | 72.56 | 34.54 lbs | 2700 |
| 18X9.5 | 6X135/6X139.7 | 4.54 | -18mm | 106.1 | 40.26 lbs | 2500 |
| 18X9.5 | 8X165.1 | 5.72 | 12mm | 122.4 | 37.04 lbs | 3640 |
| 20X9.5 | 6X135/6X139.7 | 5.72 | 12mm | 106.1 | 40.48 lbs | 2500 |
| 20X9.5 | 6X135/6X139.7 | 4.54 | -18mm | 106.1 | 44.44 lbs | 2500 |
| 20X9.5 | 8X180 | 5.72 | 12mm | 125.1 | 41.00 lbs | 3640 |
| 20X12 | 8X165.1 | 4.77 | -44mm | 122.4 | 41.89 lbs | 3640 |
Key Features
- Military-inspired tactical design — bolted wheel face and chiselled window accents draw from modern defence vehicle aesthetics for a purposeful, aggressive look
- Exceptional fitment range — 16", 17", 18", and 20" diameters across 5, 6, and 8-lug bolt patterns with offsets from -44mm to +38mm
- Suits stock and lifted builds — engineered to cover the broadest possible range of off-highway vehicles from daily drivers to serious expedition rigs
- Sand on Black finish — warm sand-toned face over a black base for a distinctive two-tone look that complements the wheel's mil-spec character
Expert Help — Australia Wide
Not sure which size, bolt pattern, or offset suits your build? Our team is available via live online chat to help you get the fitment right the first time. We deliver Australia wide with fast, tracked shipping, and offer flexible payment options including Afterpay, Zip, and major credit cards — so you can get rolling sooner.
This is to be taken as a guide only. We have listed below a few popular vehicle makes with wheel sizes & offsets.
THESE WHEELS MAY FIT OTHER VEHICLES. YOUR VEHICLE MAY ALSO BE ABLE TO FIT OTHER SIZES.
Talk with our online chat if you have quesitons about sizing.
Enter your registration number and state when you place your order and our team will ensure the correct wheel is shipped to fit your vehicle.
| VEHICLE | POPULAR SIZES | POPULAR OFFSET |
| Ford Ranger PX-PXIII No Flares (2011 - 2022) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +30 to 35mm |
| Ford Ranger PX-PXIII With Flares (2011 - 2022) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +20 to 30mm |
| Ford Ranger Next Gen No Flares (2022+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +30 to 55mm |
| Ford Ranger Next Gen With Flares (2022+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +20 to 30mm |
| Isuzu D-Max (2012 - 2020) |
18x8, 18x8.5, 18x9, 20x9 | +10 to 25mm |
| Isuzu D-Max (2021+) |
18x8, 18x8.5, 18x9, 20x9 | +10 to 25mm |
| Mazda BT50 (2011 - 2020) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +30 to 35mm |
| Mazda BT50 (2020+) |
17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 19x8.5 | +30 to 33mm |
| Mitsubishi Triton MQ (2015 - 2018) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +15 to 35mm |
| Mitsubishi Triton MR (2018+) |
18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +18 to 35mm |
| Nissan Navara D22 Series 1 (2000 - 2015) |
16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5 | +30 to 40mm |
| Nissan Navara D23 Series 3 - Cab Chassis (2015+) |
16x7 | +30 to 45mm |
| Nissan Navara D23 Series 3 - Dual Cab (2015+) |
16x7, 16x8, 17x7, 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +30 to 35mm |
| Toyota Hilux N70 KUN Facelift No Flares (2011 - 2015) |
15x6.5, 16x7 | +30 to 40mm |
| Toyota Hilux N80 GUN Revo (2015 - 2022) |
18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +15 to 30mm |
| Toyota LandCruiser 200 Series | 17x8, 17x8.5, 17x9, 18x8, 18x8.5, 18x9 | +35mm |
| Toyota LandCruiser 300 Series | 17x18x8, 18x8.5, 18x9, 20x8.5, 20x9 | +35 to 40mm |
| Volkswagen Amarok (2011+) |
16x8,17x8, 17x8.5, 18x8, 18x8.5 | +30 to 40mm |
Wheel Offset is the clearance between the inside of the wheel and the strut housing. It will also show how far the outside of the wheel edge will extend or retract. If you reduce the inner clearance too much or push the wheel out too far, the tire might rub or not fit at all. This calculator is for information purposes only and we do not guarantee fitment based on this calculator alone.
You can also try using this free online WHEEL CALCULATOR.
Our team are also available on online chat during business hours to assist in choosing the correct size wheel for your vehicle.
Checkout our range online or chat with our team via online chat if you need help choosing the right size.
Our range includes Ford Ranger wheel rims, Toyota Hilux wheel rims, VW Amarok wheel rims, Mazda BT50 wheel rims, Isuzu Dmax & MUX wheel rims, and many more.
